Construction Trades and Building Envelope

Level 3 NVQ Diploma Cladding Occupations (Construction)

A work-based Level 3 NVQ confirming advanced competence in roof and wall sheeting, cladding, rainwater goods and complex formations.

Overview

The Level 3 NVQ Diploma in Cladding Occupations (Construction) is a competence-based qualification for experienced workers installing roof and wall sheeting and cladding systems. It confirms the ability to organise work, prepare resources, install cladding systems, fit associated rainwater goods and complete more demanding work on curved and complex roof and wall formations.

The qualification reflects the practical responsibilities of an experienced cladding installer rather than an introductory trainee role. Learners are expected to interpret drawings, specifications, programmes, method statements and manufacturers' information; organise their work; select and prepare materials; use relevant tools and access equipment; and complete installation work to specified quality and safety requirements.

Core practical competence relates to systems such as built-up sheeting, standing seam, secret-fix, composite panels and fibre-cement systems. Depending on the approved qualification structure and evidence being assessed, the learner's occupational competence may be associated with a particular system endorsement.

Current approved structures require a substantial common core covering health and safety, work planning, working relationships, methods of work, resource preparation, roof and wall cladding installation, rainwater goods and curved or complex formations. Learners also complete an appropriate optional unit connected to their actual work, such as repair, refurbishment, solar collector installation, access equipment, materials handling or setting out.

Earlier versions of the Level 3 qualification included separate Roof and Wall Sheeting and Cladding and Rainscreen Wall Cladding Systems pathways. Updated versions introduced in 2026 removed the rainscreen pathway from this qualification, with rainscreen façade systems moving into a separate qualification structure. The current Level 3 qualification therefore centres on roof and wall sheeting and cladding competence.

Because this is an NVQ, achievement depends on demonstrating occupational competence through genuine work activity. It gives employers evidence that the learner can apply technical knowledge, safe working practices and installation skills consistently in a working construction environment.

Qualification structures, unit wording and assessment requirements may vary slightly depending on the approved awarding organisation.

Who It’s For

This qualification is primarily intended for experienced roof sheeting and wall cladding operatives who already carry out substantial installation work and have access to the range of activities needed to demonstrate Level 3 occupational competence. It is particularly relevant where the worker is expected to deal with more complex installations, make informed work decisions and take responsibility for the quality of their own work.

Suitable learners may work as:

Roof sheeting and cladding installers.
Industrial roofing and cladding operatives.
Experienced roof and wall cladders.
Specialist installers working with built-up, standing seam, secret-fix, composite panel or fibre-cement systems.
Operatives responsible for installing associated rainwater goods.
Cladding workers involved in complex, curved, refurbishment or repair work where the relevant optional unit is selected.

Learners normally need a genuine construction workplace in which appropriate roof and wall cladding activities occur. This may be through employment, self-employment or another legitimate workplace arrangement that allows occupational assessment.

Suitable work must provide opportunities to demonstrate activities such as preparing sheets and components, setting out, fixing and sealing cladding systems, working around openings and penetrations, installing flashings and associated components, fitting rainwater goods and carrying out work on curved or complex formations.

The qualification is not designed to establish occupational competence solely through classroom study or isolated training-centre exercises. The learner must be able to produce valid evidence from actual work.

System Endorsements and Optional Specialisms

Current qualification structures focus on roof and wall sheeting and cladding rather than dividing learners between the former roof/wall and rainscreen pathways. Within the main installation units, the work may be associated with particular cladding system types. The way an endorsement is recorded can vary between approved versions, so the learner's intended occupational scope should be confirmed before assessment begins.

Built-Up Systems

Built-up systems involve assembling the separate components that form the roof or wall construction. The learner's evidence may include preparing and installing sheets, spacer systems, insulation, membranes, fixings, flashings and associated weathering components.

Competence requires correct sequencing of the build-up, alignment of components, maintenance of interfaces and completion of joints, laps and seals in accordance with the project and manufacturer's requirements.

Standing Seam Systems

This specialism concerns standing seam roof or wall systems and the particular supporting and fixing arrangements used with them.

Work can include setting out the system, positioning halters or other specified supports, fitting sheets accurately, maintaining the required alignment and accommodating system requirements such as movement, weathering details, penetrations and flashings.

Secret-Fix Systems

Secret-fix systems use concealed fixing arrangements rather than relying solely on exposed through-fixings.

The learner must be able to prepare and install the specified support and fixing components, maintain alignment and joint integrity, deal correctly with interfaces and penetrations and complete the system without compromising its designed weather performance.

Composite Panel Systems

Composite panel competence covers the preparation and installation of factory-produced insulated roof or wall panels and their associated components.

Typical work includes handling and positioning panels without damage, maintaining line and level, installing specified fasteners and seals, forming junctions and interfaces and completing flashings, openings and penetrations to the required standard.

Fibre-Cement Systems

Fibre-cement work requires competence in preparing, handling, positioning and fixing the relevant sheets and components while following the manufacturer's installation requirements.

The work includes maintaining correct laps and fixing arrangements, avoiding damage during handling and installation, completing weathering details and applying the particular safety controls required for the materials and working environment.

Workplace Requirements

Workplace access is fundamental to this qualification. The learner needs sufficient opportunities to demonstrate the required activities under genuine construction-site conditions and across a scope of work broad enough to establish occupational competence.

Relevant workplace access may need to include:

Roof and wall areas where sheeting or cladding is being prepared and installed.
The cladding system against which the learner's occupational competence is being assessed.
Drawings, specifications, schedules, risk assessments, method statements and manufacturers' instructions.
Appropriate sheets, panels, fixings, fasteners, flashings, fittings and system components.
Insulation, vapour control layers, separation or breather membranes where required by the installation.
Sealants, fillers, tapes, primers and other materials needed to complete interfaces and maintain weather performance.
Hand tools, portable power tools and associated equipment used for measuring, marking, cutting, preparing, positioning and fixing materials.
Suitable access and work-at-height arrangements.
Opportunities to install rainwater goods and associated roof or wall drainage components.
Curved or otherwise complex roof and wall formations that allow the mandatory advanced installation competence to be demonstrated.
Relevant plant, MEWPs, manipulating equipment, solar collector work, repair work or setting-out activities where one of those optional units is selected.

Evidence must arise from work for which the learner has appropriate responsibility and authority. Activities requiring a separate licence, authorisation, specialist competence or statutory control must remain within the learner's permitted scope.

Where existing materials or buildings may contain hazardous substances, the learner must recognise the issue, follow the required procedures and refer work that falls outside their competence or authorisation rather than disturbing materials inappropriately.

Learning Outcomes

Successful learners demonstrate that they can combine technical knowledge with competent workplace performance in roof and wall sheeting and cladding. Across the qualification, this includes the ability to:

Interpret drawings, specifications, programmes, schedules, method statements, risk assessments and manufacturers' information relevant to cladding work.
Confirm the work activities, resources and sequence required for their occupational work area.
Develop and maintain effective working relationships with colleagues, supervisors, customers and other occupations.
Establish an appropriate method of work and communicate information needed to carry it out safely and efficiently.
Identify, check, measure, mark, cut, prepare and position sheeting, cladding materials and associated components.
Select and use appropriate hand tools, power tools and ancillary equipment.
Prepare resources for the specified roof or wall cladding system.
Set out, align, level, fit, fix and finish sheeting and cladding systems accurately.
Install the relevant supporting components, fixings, flashings, membranes, insulation and sealing materials required by the system.
Deal correctly with openings, penetrations, upstands, junctions and interfaces.
Maintain joints, overlaps and weathering details in accordance with installation requirements.
Install rainwater goods and associated drainage components on clad roofs and walls.
Carry out installation work on curved and complex roof or wall formations.
Apply controls for work at height, manual handling, mechanical access, power tools, substances and other occupational hazards.
Protect materials, completed work and the surrounding environment from avoidable damage.
Check completed work against drawings, specifications, manufacturers' requirements and relevant inspection or quality requirements.
Recognise defects, unsuitable resources or circumstances outside personal authority and report them correctly.
Coordinate work with other trades and complete activities within the agreed work programme.
Segregate, handle and dispose of waste in accordance with workplace and environmental requirements.
Produce evidence of additional competence in the optional occupational area selected for the qualification.

Units

Current approved structures use eight mandatory units that establish the common Level 3 competence required in roof and wall sheeting and cladding. The learner then completes one appropriate optional unit. Optional choices should reflect work the learner genuinely performs, and availability or endorsement arrangements can vary between approved qualification versions.

Follow site inductions, briefings, risk controls and agreed safe systems of work.
Comply with safety signs, notices, exclusion arrangements and organisational procedures.
Use the required personal protective and other health and safety control equipment correctly.
Recognise hazards and changes in site conditions that could affect the planned cladding work.
Stop or report work where an unforeseen risk or unsafe condition falls outside personal authority.
Follow workplace procedures for emergencies, evacuation, fire and accident reporting.
Maintain safe access, working areas and appropriate housekeeping.
Handle and dispose of waste without creating unnecessary health, safety or environmental risks.
Work in a way that protects colleagues, other site users and members of the public where relevant.

Interpret project information to establish the required roof or wall activities.
Identify work priorities, interfaces, planned sequences and programme requirements.
Confirm the materials, fixings, components, tools, equipment and access resources needed.
Check that resources are suitable, available in the required quantities and compatible with the work.
Identify unsuitable, damaged or insufficient resources and follow procedures for resolving the issue.
Consider alternative resources or methods where authorised and technically appropriate.
Organise the work area so that materials and equipment can be used safely and efficiently.
Coordinate requirements with other trades and relevant site personnel.
Communicate circumstances that may affect the planned programme or completion of the work.

Communicating clearly with colleagues, supervisors, customers and other relevant people.
Giving and receiving information needed to coordinate work safely.
Cooperating with other occupations where work areas, access or construction interfaces overlap.
Responding constructively to requests for information or assistance.
Maintaining professional behaviour and trust while carrying out work.
Identifying potential disagreements or coordination problems and dealing with them within personal authority.
Reporting unresolved issues through the correct workplace channels.
Keeping relevant people informed when changes to the cladding work may affect their activities.

Review drawings, specifications, schedules, programmes, risk assessments and method statements.
Identify the sequence required to complete the cladding activities.
Consider access, work-at-height arrangements, material movement and workplace restrictions.
Determine the tools, equipment, materials and people needed for the planned method.
Take account of safety, environmental and quality requirements when confirming the method.
Identify information that is incomplete, inconsistent or unsuitable and report it appropriately.
Recognise when specialist knowledge or additional authority is required.
Communicate the agreed method and relevant changes to those affected by the work.
Adapt within authorised limits when workplace circumstances affect the original plan.

Interpret drawings, specifications, setting-out information, schedules, fixing requirements and manufacturers' instructions.
Identify the correct sheet profiles, panels, fixings, flashings, components and associated materials.
Check materials for type, dimensions, quantity, condition and suitability before installation.
Measure, mark out, cut, prepare and position materials accurately.
Prepare resources for the relevant built-up, standing seam, secret-fix, composite panel or fibre-cement system.
Use and maintain hand tools, power tools and associated equipment correctly.
Handle, move and store sheets and components to minimise damage and unnecessary risk.
Take account of gridlines, datums, installation direction and other setting-out information.
Protect prepared materials and components until they are required.
Identify defects, shortages or incompatible resources and report them before they compromise the installation.

Interpret installation drawings, specifications, schedules, fixing information and manufacturers' requirements.
Select and use suitable sheets or panels, fixings, fasteners, flashings, fittings and supporting components.
Work with associated materials such as insulation, vapour control layers, separation or breather membranes, sealants and fillers where required.
Measure, set out, adjust, align, level, plumb, fit, fix and finish the installation.
Install the relevant built-up, standing seam, secret-fix, composite panel or fibre-cement system.
Form and complete details around openings, penetrations, upstands, vents and other interfaces.
Fit flashings and associated weathering components correctly.
Maintain specified joints, laps and interfaces throughout the system.
Apply tapes, fillers and sealants where required to maintain the designed air and weather performance.
Use access equipment and work-at-height controls appropriate to the task.
Protect finished surfaces and avoid unnecessary damage to coatings or components.
Inspect the completed installation, identify defects or deviations and take action within personal authority.
Complete the work in accordance with the programme and coordinate interfaces with other occupations.

Interpret drawings, specifications and manufacturers' information for the rainwater system.
Select appropriate brackets, supports, fixings, gutters, pipes and associated components.
Measure, mark out, cut, line, level, adjust, position, fix and secure rainwater goods.
Establish the required datum and positioning of supports and drainage components.
Install gutters, downpipes, outlets and angles to the working instructions.
Work with membrane-lined gutters where these form part of the specified installation.
Fit relevant stop-ends, guards, covers, overflows, sumps and outlets.
Use the specified sealants, gaskets or jointing arrangements.
Maintain interfaces between the rainwater goods and the roof or wall cladding.
Check the finished work against project, manufacturer and quality requirements.
Identify installation defects or drainage issues and report or rectify them within personal authority.

Interpret drawings and other information relating to curved or complex formations.
Establish relevant gridlines, datums, dimensions, orientation and direction of installation.
Plan the sequence and positioning of materials for complex work areas.
Measure, set out, position, fit, line, level and secure sheets, panels and associated components.
Prepare and install materials to curved surfaces and complex roof or wall formations.
Deal with changes in geometry, intricate junctions and more complex flashing requirements.
Cut, shape or prepare components where required by the design and system.
Install relevant insulation, membranes, fire-stopping components and sealing materials where specified.
Maintain the designed interfaces, weathering and system integrity through complex details.
Use appropriate tools, powered equipment and access arrangements safely.
Check the completed formation against the required specification and manufacturers' criteria.
Recognise situations that require specialist input and report them before proceeding.

Assess the existing installation and interpret the information governing the refurbishment.
Identify, check, measure, mark, cut, remove, clean, replace, align, position, fix and seal materials.
Prepare existing backgrounds and resources for refurbishment, re-sheeting or over-cladding.
Carry out work on the relevant built-up, standing seam, secret-fix, composite panel or fibre-cement system.
Determine the appropriate sequence for removing or retaining existing materials.
Recognise requirements relating to hazardous substances and follow the applicable procedures and limits of personal authority.
Protect the structure and surrounding materials during stripping and replacement work.
Replace associated membranes, insulation, fixings, flashings and weathering components where specified.
Maintain joints, penetrations, interfaces and seals in the refurbished system.
Segregate and dispose of removed materials correctly.
Check the completed work against the specification and report defects or unsuitable existing conditions.

Interpret the information and repair requirements for the existing system.
Identify defects such as leaks, condensation, damaged sheets or components, minor coating defects and damaged or missing flashings.
Establish the likely source of water ingress or condensation before choosing a repair method.
Remove, replace, renew and repair affected materials and components.
Match replacement materials appropriately to the existing system.
Repair or replace defective sheets, fittings, fixings and flashings.
Check joints, overlaps and interfaces that may be contributing to failure.
Reinstate sealants, fillers and other weathering measures where required.
Inspect and repair associated rainwater goods where the defect relates to the drainage system.
Reinstate relevant insulation, fire stops, breather membranes or vapour control layers when required by the repair.
Check completed repairs against the specified quality and manufacturer's criteria.
Report defects requiring work beyond the learner's authority or occupational competence.

Interpret the installation information and assess the intended roof area.
Check the orientation, positioning and dimensions relevant to the collector installation.
Remove or omit roof covering components where required by the specified system.
Measure, mark out and prepare the installation position.
Prepare and weatherproof required roof penetrations.
Fit additional supports where specified.
Position, fit, fix and secure integrated or mounted collectors.
Work with the applicable photovoltaic or solar-thermal collector arrangement.
Reinstate surrounding roof coverings to the working instructions.
Handle collectors, roof materials and equipment safely.
Use hand tools, portable power tools and ancillary equipment correctly.
Work within personal authority and coordinate any specialist electrical, plumbing or commissioning activities that require separate competence.

Interpret relevant instructions, lift information, risk assessments and manufacturers' requirements.
Organise the sequence of lifting and transferring activities with other team members.
Check the machine and confirm that required inspection or examination information is valid.
Select suitable ancillary equipment and accessories.
Prepare and set up the machine for the planned operation.
Check, adjust, communicate, operate, manoeuvre and position the equipment safely.
Lift, transfer, position and set down loads in accordance with the working instructions.
Maintain effective communication with people involved in the activity.
Respond appropriately to changing ground, access or workplace conditions.
Shut down and secure the machine after use.
Report equipment defects or circumstances outside the operator's authority.

Interpret the information governing the access operation and planned work area.
Check relevant machine documentation and pre-use requirements.
Assess ground conditions, stability, obstructions and the surrounding work area.
Select and use required access-related resources and safety controls.
Prepare, position, set up and adjust the scissor-type MEWP.
Communicate with relevant personnel before and during movement or positioning.
Manoeuvre and position the platform to provide safe access to the work area.
Recognise operational restrictions and potential hazards.
Use the platform within its permitted operating limits and working instructions.
Shut down and secure the MEWP correctly after use.
Report defects or unsafe conditions before further operation.

Interpret the planned access requirements and working instructions.
Confirm relevant machine checks, inspection information and operating requirements.
Assess ground conditions, stability, overhead restrictions and nearby obstructions.
Recognise potential entrapment and collision risks within the operating area.
Use the specified fall-prevention or restraint arrangements.
Prepare, set up, adjust and position the boom-type MEWP.
Manoeuvre the platform while maintaining awareness of structures, services and other site users.
Communicate effectively during access operations.
Reach and position at the required work area within the machine's operating limits.
Set down, shut down and secure the equipment correctly.
Report faults or changing conditions that make continued operation unsafe.

Interpret instructions relevant to the mast-climber access operation.
Check required machine documentation and pre-operational information.
Assess the work area for stability, obstructions and other hazards.
Identify the operating characteristics and limits of the mast-climber.
Prepare, set up, adjust and position the platform for the required work.
Operate and manoeuvre the equipment in accordance with the working instructions.
Maintain awareness of potential entrapment, structures and services.
Apply relevant fall-prevention measures and other safety controls.
Communicate with people affected by platform movements and access arrangements.
Secure the platform appropriately when work is complete.
Report defects, unsafe conditions or situations beyond personal authority.

Interpret drawings, dimensions, datums and other setting-out information.
Establish the secondary controls required for the work.
Transfer, transpose, level, measure, mark, position, fix and secure setting-out information.
Use suitable hand tools and measuring and marking equipment.
Establish the required lines, levels, depths, areas, heights or angles relevant to the work.
Measure and align the work against dimensional control requirements.
Transfer lines, angles and levels accurately from the specified references.
Carry out calculations required for height, depth, length, area or angles.
Work safely where setting out requires access at height.
Check the accuracy of transferred information before installation proceeds.
Recognise discrepancies or requirements for specialist surveying knowledge and report them appropriately.
Communicate dimensional information clearly to other people relying on the setting out.

Assessment

Assessment is based on demonstrated occupational competence rather than attendance alone. The learner must provide sufficient evidence that the mandatory requirements and the selected optional unit have been achieved in the context of genuine roof and wall sheeting and cladding work.

Workplace Observation and Practical Performance

Direct evidence from normal work is a primary form of assessment. An assessor may observe the learner preparing materials, organising the work area, installing cladding, fitting rainwater goods, completing complex formations or carrying out the activity relevant to the selected optional unit.

Observed performance can establish competence in areas such as:

Interpreting and following installation information.
Preparing sheets, panels, flashings and system components.
Measuring, marking, cutting and setting out.
Using hand tools and powered equipment.
Installing and aligning cladding systems.
Completing joints, laps, seals, flashings and interfaces.
Using appropriate controls for work at height.
Installing rainwater goods.
Working on curved and complex formations.
Inspecting work and dealing appropriately with defects.
Coordinating work with colleagues and other occupations.

Assessment evidence must demonstrate the learner's own contribution where activities are undertaken by a team.

Portfolio Evidence and Work Products

A portfolio brings together evidence showing how competence has been applied across the qualification. Evidence is expected to relate clearly to real work and to be authentic, current and sufficient for the requirements being assessed.

Relevant evidence may include:

Photographs or video supporting observed installation activity.
Completed cladding, flashing, rainwater or complex-detail work.
Relevant extracts from job documentation used by the learner.
Installation and inspection records.
Check sheets and quality documentation.
Records showing material or component checks.
Work records demonstrating repair or refurbishment activities.
Evidence of setting-out work where that optional unit is selected.
Records associated with plant or access-equipment checks where relevant.
Employer or workplace records that substantiate the learner's activities.

Photographs or records do not automatically prove competence on their own. They must be linked to the learner's work and considered with other valid evidence.

Professional Discussion, Questioning and Witness Evidence

Practical performance must be supported by evidence that the learner understands why the work is carried out in a particular way.

Professional discussion or oral or written questioning may be used to confirm knowledge of:

Cladding materials and system components.
Installation sequencing and preparation.
Drawings, specifications and manufacturers' information.
Fixing, sealing and weathering principles.
Quality requirements and defect identification.
Work-at-height and access controls.
Manual handling and mechanical movement of materials.
Environmental responsibilities and waste management.
Actions required when existing materials may be hazardous.
Reporting procedures and limits of personal authority.

Suitable witness testimony can contribute where the witness has directly observed relevant performance and is able to give reliable evidence. It supports, rather than automatically replaces, the broader evidence needed to demonstrate competence.

Simulation and Consistency of Evidence

The practical competence required for this qualification must be demonstrated through real workplace activity. Current qualification requirements do not treat simulated cladding exercises as a substitute for the required workplace performance evidence.

The evidence, taken as a whole, must show consistent competence across the applicable learning outcomes and assessment requirements. A single isolated example may therefore be insufficient where the occupational standard requires the learner to demonstrate reliable performance across the scope of the work.

Knowledge that cannot be fully demonstrated from a particular work product may be confirmed through questioning, professional discussion or other suitable evidence. Previous evidence or experience may also be considered where it remains authentic, relevant, current and capable of being mapped to the qualification requirements.

To achieve the Diploma, the learner must satisfy all mandatory competence requirements and successfully complete the required optional unit.

Career Progression

Achievement provides formal recognition of advanced occupational competence in roof and wall sheeting and cladding. Progression depends on the worker's actual experience, employer requirements, additional responsibilities and any specialist training needed for the next role.

Experienced Roof Sheeting and Cladding Roles

The qualification is directly relevant to experienced roles such as:

Roof sheeting and cladding installer.
Industrial roofing and cladding operative.
Advanced roof and wall cladding operative.
Specialist system installer.

The system against which the learner has demonstrated competence can influence the type of work they are best prepared to undertake.

Specialist Installation and Refurbishment Work

Experienced installers may continue developing in areas such as:

Built-up roof and wall systems.
Standing seam systems.
Secret-fix systems.
Composite panel installation.
Fibre-cement sheeting.
Complex and curved cladding work.
Cladding repair and refurbishment.
Associated rainwater systems.
Solar collector installation where the worker has the appropriate occupational responsibilities.
Specialist access or materials-handling operations where appropriate competence and authorisation are held.

Rainscreen façade systems are now covered through a separate current qualification structure rather than the updated Level 3 cladding qualification, so workers moving specifically into rainscreen installation should follow the qualification route applicable to that occupation.

Supervision and Further Development

An experienced cladding installer may progress towards team-leading or supervisory responsibilities where their role develops to include greater responsibility for people, resources, coordination and work quality.

Possible further development can include qualifications in occupational work supervision or construction site supervision when the individual's job role provides the required level of supervisory responsibility.

Moving into supervision, management, specialist plant operation or other regulated activities may require additional qualifications, training, authorisations or experience beyond this Diploma.

CSCS Card

The qualification has a verified occupational card route for roof sheeting and cladding. The current mapping for the Roof Sheeting and Cladding occupation identifies the Level 3 NVQ Diploma in Cladding Occupations (Construction) – Roof Sheeting and Cladding as supporting the Gold Advanced Craft CSCS card.

The qualification does not automatically issue a CSCS card or guarantee that an application will be accepted. Card applications are separate from qualification certification and must satisfy the scheme requirements in force at the time of application.

For the mapped Roof Sheeting and Cladding occupation:

The relevant card is the Gold Advanced Craft card.
The mapped occupation is Roof Sheeting and Cladding.
The specified CITB Health, Safety and Environment test is the Specialist Work at Height test.
The appropriate test normally needs to have been passed within the two years preceding the card application, unless an approved alternative applies.
Applicants must submit the required qualification and application evidence separately.
The occupational mapping must correspond with the qualification and competence actually achieved.

Older Level 3 versions also contained a Rainscreen Wall Cladding Systems pathway. Current qualification structures have separated rainscreen façade competence from this qualification, so a worker seeking a card specifically for specialist rainscreen work should not assume that the current roof and wall cladding qualification gives the same occupational mapping.

Applicants should always confirm the current occupation, qualification and test requirements through the official CSCS Card Finder before applying.

FAQs

These questions address practical issues that are particularly important for workers considering the current Level 3 qualification, including changes to the qualification structure, workplace evidence, cladding system scope and assessment.

No. Older versions included separate Roof and Wall Sheeting and Cladding and Rainscreen Wall Cladding Systems pathways.

Current updated versions focus the Level 3 Diploma on roof and wall sheeting and cladding. Rainscreen façade systems have moved into a separate qualification structure, so learners should make sure they are registered for the qualification that matches the occupation they actually perform.

Yes. This is a work-based occupational competence qualification. The learner needs access to genuine work that allows the required roof and wall cladding skills to be demonstrated and assessed.

The workplace must provide sufficient opportunities to cover the mandatory activities and the optional unit chosen for the learner's qualification.

Current structures recognise the main system types used within the occupational standards, including:

Built-up systems.
Standing seam systems.
Secret-fix systems.
Composite panel systems.
Fibre-cement systems.

The relevant preparation and installation evidence must match the system against which the learner's competence is being assessed. Formal endorsement arrangements can differ slightly between approved qualification versions.

No. Repair and refurbishment or replacement are optional units rather than additional universal mandatory units in the current structure.

The learner completes the mandatory units and the required optional choice. The optional unit should be selected according to the learner's genuine workplace activities and the approved structure being followed.

Yes, current structures include optional units relating to scissor-type, boom-type and mast-climber-type mobile elevating work platforms.

Selecting one of these units means the learner must be able to produce appropriate evidence of preparing and operating that particular equipment in the workplace. Inclusion of an NVQ unit does not remove any separate site, employer, manufacturer or legal requirements governing the use of access equipment.

The qualification is intended to confirm real occupational competence, and current requirements specify workplace evidence for practical performance. Simulated cladding exercises are not a substitute for the workplace skills that must be demonstrated.

Knowledge may be confirmed through methods such as questioning or professional discussion, but the installation and other occupational skills themselves require suitable evidence from real work.

Yes. Installing sheeting and cladding systems to curved and complex roof and wall formations is part of the current mandatory structure.

The learner therefore needs suitable workplace opportunities to demonstrate more demanding installation work involving complex geometry, setting out, fitting, shaping, interfaces and associated detailing rather than relying only on straightforward roof or wall areas.

For the Roof Sheeting and Cladding occupation, the Level 3 NVQ route is mapped to the Gold Advanced Craft CSCS card. The current mapped health, safety and environment test is the Specialist Work at Height test.

The Diploma does not itself issue the card. A separate application is required, the occupational mapping must match the qualification achieved, and current requirements should be checked through the CSCS Card Finder before applying.

Application Form
